Description

Features

Intergral or Welded Flanges
Two piece self aligning packing gland
Captured Graphite Spiral wound gasket
Integral backseat
Flange Dimensions ANSI B16.5
NACE MR-01-75

Standards

API-602
BS 5352
ANSI B16.34
API-598
MSS SP-25
Range
1/2~2”(DN15~DN50)
150~2500LB(PN16~PN420)
A105N, LF2, F11, F22, F304,F316, F304L, F316L, F317, F321, F347, INCONEL, MONEL, H.C
End Connection: NPT, SW, RF, RJT, BW
